起源の場所:
シャインクシ、Xian
ブランド名:
SHACMAN
証明:
ISO 9001/CCC
モデル番号:
F3000
| Model | SX5255JSQDR584 |
|---|---|
| Drive type | 6x4 |
| Weight | Gross Vehicle Weight ≤35 |
| Dimensions | Wheelbase/(mm) 5775+1400 |
| Performance | Maximum speed/(km/h) 50～70/90 |
| Ground clearance | >314 |
| Engine |
Brand: WEICHAI Model: WP10.340E22 Power/(kw/HP): 250kw / 300Hp Maximum torque / (N.M)/rpm: 1400 N*M Displacement/(L): 9.726 L Emission standard: Euro/ II |
| Gear box |
Brand: FAST Model: RTD-11509C+QH50 |
| Clutch | Type: φ430 Diaphragm spring clutch |
| Cooling | Type: Domestic heat sink |
| Air inlet | Type: Ordinary air filter |
| Brakes |
Type: Drum brake Service brake: Double circuit air brake Park brake: Rear wheel spring brake Auxiliary brake: WEVB engine exhaust brake |
| Steering | Type: ZF8098 technology, circulating ball steering machine |
| Chassis |
Type: Parallel trapezoidal frame with variable section Dimensions/(mm): 850×300(8+5+8) |
| Suspension |
Front: Multi-layer plate spring 4 main plates + 4 U-shaped bolts Rear: Multi-layer plate spring 4 main plates + 4 U-shaped bolts |
| Axles |
Brand: HANDE Front axle: 7.5T front axle MAN technology Rear axle: 16T MAN Double Reduction Drive axle with inter helix differential and differential lock, bridge speed ratio: 4.769 |
| Tires | Type: 12.00R20 |
| Fuel tank | Tank capacity/(L): 300L Aluminum tank |
| Electrics |
Type: 24V Battery: 165Ah Maintenance-free battery |
| Cab |
Type: SHACMAN F3000 Medium-length flat cab Equipment: Hydraulic main seat, four-point hydraulic suspension cab, manual window crank, ordinary rear-view mirror, square muffler, 165Ah maintenance-free battery, SHACMAN logo, full English logo. |
問い合わせを直接私たちに送ってください.
